Connectivity & Integration

Built for Modern Control Systems

Modern motor control isn’t only about power electronics — it’s also about visibility, control, and integration.

SmartD Clean Power VFD technology is designed to integrate cleanly into existing plant infrastructure, making it easy to connect drives to PLC, SCADA, BAS, and service tools while maintaining a simple commissioning and support experience.

Why Connectivity & Integration Matters

Connectivity reduces friction across the full lifecycle — from commissioning to operations to troubleshooting.

Faster Commissioning

Standardized connectivity and clear data points simplify startup and validation.

Operational Visibility

Access to drive status, alarms, and performance metrics supports better decision-making.

Simpler Troubleshooting

Clear diagnostics and consistent data reduce downtime and service effort.

Scalable Standardization

A repeatable integration approach makes it easier to scale across multiple sites and applications.

Typical Integration Challenges

Many drive installations become harder to operate over time because integration is treated as an afterthought.

Common challenges include:

Inconsistent signal mapping from drive to PLC/SCADA
Limited visibility into drive health, faults, and runtime history
Time-consuming commissioning due to non-standard setups
Difficulty supporting remote sites without clear diagnostics
Control networks that require careful coordination and documentation

Clean integration solves these issues by making the drive easy to connect, easy to monitor, and easy to support.

The SmartD Approach to Connectivity

SmartD Clean Power VFD is designed to integrate into automation systems with a practical, operator-friendly data model.

Dual Ethernet – Native Protocols

EtherNet/IP
Modbus TCP
BACnet/IP

Enabling real-time monitoring and control of:

Motor current
Voltage
Speed
Torque
Fault status

Flexible Network Topologies

Star topology
Daisy chain
Ring

All network parameters (IP address, subnet, gateway) are fully configurable via HMI or network menus.

What integrators can expect

Drive-ready signals for run/stop, speed reference, status, faults, and warnings

Common operational feedback such as speed, current, voltage, power, and energy

Reliability-focused data such as uptime, event history, and trip cause context

Clear status indicators for STO state (when equipped), comms health, and drive readiness

Key Benefits

Integrate with PLC / SCADA / BAS systems without custom workarounds
Reduce commissioning time with consistent mapping and documentation
Improve troubleshooting with clearer diagnostics and event history
Enable remote support workflows for distributed or remote sites
Standardize drive integration across multiple facilities

Ideal Applications

Connectivity and integration benefits are especially valuable in:

Municipal water and wastewater
Data center cooling infrastructure
HVAC and district energy plants
Industrial pumping systems
Manufacturing facilities
Remote infrastructure where service access is limited

Real-World Retrofit Example

In many retrofit projects, electrical rooms were not designed to accommodate large external mitigation equipment.

By installing SmartD Clean Power VFDs, facilities can often remove external filters and simplify cabinet layouts while improving power quality.

This approach allows existing infrastructure to be modernized without expanding electrical rooms or adding complex hardware.

Mobile app enables online or offline configuration, monitoring of alarms and even local motor control.

It allows faster commissioning, simpler troubleshooting and deployment costs savings.

COMPLETE CONTROL WITH SEAMLESS CONNECTIVITY

Our team will assess your system and recommend the right integration into your automation systems.
